Kamera inspeksi genggam dengan AutoFocus dan AutoCentering, menilai konektor MPO maupun serat tunggal secara otomatis sesuai IEC 61300-3-35. MPO 8 sampai 32 serat dinilai kurang dari dua detik, hasilnya dikirim lewat WiFi ke LinkWare. Cocok untuk tim pusat data yang mengecek end face sebelum kabel dipasang.
| type | Inspection probe |
|---|
| inspection | 5 MP CMOS, auto pass/fail IEC 61300-3-35, FOV 610 × 460 µm |
|---|
| standards | IEC 61300-3-35 Ed. 2 |
|---|
| test time | Under 2 seconds per fiber |
|---|
| fibers per test | MPO 8 to 32 fibers (1×8, 1×12, 1×16, 2×12, 2×16) |
|---|
| connector | Single fiber and MPO, UPC or APC |
|---|
| builtin | White LED port illumination |
|---|
| battery | Lithium ion, 10.8 hour life |
|---|
| connectivity | USB, WiFi, Versiv, mobile app |
|---|
| weight | 326 g |
|---|
| dimensions | 168 × 137 × 54 mm |
|---|
| operating temp | −10 to 45 °C |
|---|
